Imagine you just finished a web application with Python 3.10 and PostgreSQL 14. Everything runs smoothly on your laptop. But once moved to the production server... boom! Errors appear everywhere.

It turns out the server still uses Python 3.6 and PostgreSQL 10. You're stuck tweaking configurations just to make the server environment match your local setup. And the classic complaint emerges:

"But it works on my laptop! 😅"

This isn't a new problem. Environment inconsistencies like this have become daily drama for developers. Not to mention when one server is forced to run various applications with different versions and requirements. Dependency conflicts become unavoidable.

And this is where Docker emerges as a solution.

1. Introduction to Containerization and Docker

What is Containerization?

Containerization is a method for packaging applications along with all their dependencies into a single unit called a container. Unlike Virtual Machines (VMs) that require separate operating systems for each instance, containers simply share the kernel from the host OS, making them lighter, faster, and more efficient.

Container:
- Focuses on application isolation, not OS
- Lightweight size (measured in MB), fast to run, and resource-efficient
- Suitable for running many applications separately without conflicts
Virtual Machine (VM):
- Runs a complete OS on top of the host through a hypervisor
- Large size (measured in GB), slow, and resource-wasteful because each VM carries its own OS

What is Docker?

Docker is a popular platform for creating, running, and managing containers. With Docker, you can ensure that applications working locally will run the same way on any server without needing to reconfigure the environment from scratch.

The workflow in Docker follows this sequence: Dockerfile → Image → Container.

Dockerfile: A text file containing instructions for building an image. Like a recipe or source code.
Docker Image: The result of a Dockerfile. Read-only in nature, contains everything the application needs. Can be considered as a blueprint.
Docker Container: The runtime version of an image. This is where the application actually runs. One image can be used to create many containers.

2. Understanding Docker Architecture

Docker has a modular and efficient architecture, enabling isolated and consistent container management. Here are its main components:

The diagram above illustrates Docker's basic architecture and the workflow between main components: Client, Docker Host, and Docker Registry.

Client is the user interface that runs commands like docker build, docker pull, and docker run
These commands are sent to the Docker Daemon running inside the Docker Host, which is the machine where Docker is executed
Inside the Docker Host, there's management of images and containers. Docker Daemon also interacts with Docker Registry to pull or push images

Based on the architecture above, let's study Docker components in more detail, including additional components that support the Docker ecosystem:

Docker Engine

Docker Engine is the core of the Docker platform running inside the Docker Host (physical or virtual machine). Its main components include:

Docker Daemon (dockerd): Background process that manages images, containers, networks, and volumes
Docker Client (docker CLI): Command interface for users like docker run, docker build, etc.
REST API: Connector between CLI and daemon to execute commands

Docker Image

Docker Image is a read-only blueprint containing all components needed to run an application, including code, dependencies, and instructions from Dockerfile.

Created using the docker build command
Stored locally or in registries like Docker Hub

Docker Container

Docker Container is a runtime instance of an image. Containers run applications lightly and in isolation, while still sharing the kernel with the host system.

Similar to applications run from an installer
Can be created, run, stopped, and deleted flexibly

Docker Registry

Docker Registry is a service for storing and distributing Docker images.

Can be public (Docker Hub) or private (GitLab, ECR, etc.)
Used with docker pull and docker push commands

Docker Networking

Docker Networking manages communication between containers and with external networks.

Bridge (default): Internal network within one host between containers
Host: Container directly uses host network, without isolation
Overlay: Connects containers across different hosts (especially in Docker Swarm)

Docker Volume

Docker Volume is used to store data persistently, even when containers are deleted.

Managed directly by Docker in special host directories
Safer and more stable than bind mounts, ideal for production environments

Docker Compose

Docker Compose is a tool for organizing and running multi-container applications easily.

Uses docker-compose.yml file to define services, networks, volumes, and other dependencies declaratively

3. Getting Started with Docker

Docker Installation

Docker can be installed on almost all major operating systems:

Windows & macOS: Use Docker Desktop which provides GUI and CLI

🔗 Download Docker Desktop
Linux: Install Docker Engine through official repositories according to each distribution

🔗 Linux Installation Guide

Managing Docker Images and Docker Containers

Here are basic commands for managing Docker images and Docker Containers.

Docker Image

bash

# View Image List
docker image ls

# Download Image from Registry
docker image pull <image_name>:<tag>

# Delete Image
docker rmi <image>

# View Image List
docker image ls

# Download Image from Registry
docker image pull <image_name>:<tag>

# Delete Image
docker rmi <image>

Docker Container

bash

# Create Container
docker container create --name <container_name> <image_name>:<tag>

# Run Container
docker container start <container_name>

# Stop Container
docker container stop <container_name>

# Delete Container (Make sure container is stopped)
docker container rm <container_name>

# View Container List
docker container ls       # active ones
docker container ls -a    # all (including stopped)

# View Logs
docker container logs <container_name>
docker container logs -f <container_name> # real-time

# Enter Container (exec)
docker container exec -it <container_name> bash

# Port Forwarding (forward port from container to host)
docker container create --name web --publish <host_port>:<container_port> <image_name>:<tag>

# Environment Variable
docker container create --name <container_name> \
  --publish <host_port>:<container_port> \
  --env <VAR1>=<value1> \
  --env <VAR2>=<value2> \
  <image_name>:<tag>

# View Resource Statistics
docker container stats

# Limit Resources
docker container create --name <container_name> \
  --memory <memory_amount> \
  --cpus <cpu_amount> \
  <image_name>:<tag>

# Create Container
docker container create --name <container_name> <image_name>:<tag>

# Run Container
docker container start <container_name>

# Stop Container
docker container stop <container_name>

# Delete Container (Make sure container is stopped)
docker container rm <container_name>

# View Container List
docker container ls       # active ones
docker container ls -a    # all (including stopped)

# View Logs
docker container logs <container_name>
docker container logs -f <container_name> # real-time

# Enter Container (exec)
docker container exec -it <container_name> bash

# Port Forwarding (forward port from container to host)
docker container create --name web --publish <host_port>:<container_port> <image_name>:<tag>

# Environment Variable
docker container create --name <container_name> \
  --publish <host_port>:<container_port> \
  --env <VAR1>=<value1> \
  --env <VAR2>=<value2> \
  <image_name>:<tag>

# View Resource Statistics
docker container stats

# Limit Resources
docker container create --name <container_name> \
  --memory <memory_amount> \
  --cpus <cpu_amount> \
  <image_name>:<tag>

Inspection and Cleanup (Inspect & Prune)

bash

# View object details in JSON format
docker inspect <object_name>

# Remove stopped containers
docker container prune

# Remove unused images
docker image prune

# Remove all unused resources
docker system prune

# View object details in JSON format
docker inspect <object_name>

# Remove stopped containers
docker container prune

# Remove unused images
docker image prune

# Remove all unused resources
docker system prune

Dockerfile and Building Images

Dockerfile is a script containing sequential instructions for building a Docker image. With Dockerfile, we can automatically and consistently package applications along with all their dependencies into a container.

Basic Dockerfile Template

plaintext

# Use base image
FROM python:3.12

# Set working directory
WORKDIR /app

# Copy & install dependencies
COPY requirements.txt .
RUN pip install -r requirements.txt

# Copy entire application files
COPY . .

# Expose port 8000
EXPOSE 8000

# Default command when container is run
CMD ["python", "app.py"]

# Use base image
FROM python:3.12

# Set working directory
WORKDIR /app

# Copy & install dependencies
COPY requirements.txt .
RUN pip install -r requirements.txt

# Copy entire application files
COPY . .

# Expose port 8000
EXPOSE 8000

# Default command when container is run
CMD ["python", "app.py"]

Important Dockerfile Instructions

Instruction	Function
`FROM`	Specify base image
`WORKDIR`	Working directory in container
`COPY`	Copy files from host to image
`RUN`	Execute command during build
`EXPOSE`	Open application port
`CMD`	Default command when container is run

Build & Run

bash

# Build image from Dockerfile
docker build -t <image_name> .

# Run container from image
docker run -d --name <container_name> -p <host_port>:<container_port> <image_name>

# View container logs
docker logs <container_name>

# Build image from Dockerfile
docker build -t <image_name> .

# Run container from image
docker run -d --name <container_name> -p <host_port>:<container_port> <image_name>

# View container logs
docker logs <container_name>

Build Optimization with `.dockerignore`

The .dockerignore file is used to exclude unnecessary files when building images, thereby improving security, reducing image size, and speeding up build time.

How to Use
1. Create a file named .dockerignore in the project root directory (same location as Dockerfile)
2. Fill the file with names of files/folders you want to ignore. The syntax is similar to .gitignore, using # for comments and ! for exceptions

Example .dockerignore content

plaintext

# Git & dependencies
.git
node_modules/
__pycache__/

# Log files and environment
*.log
.env

# Operating system & IDE files
.DS_Store
.vscode/

# Docker files themselves
Dockerfile
.dockerignore
docker-compose.yml

# Git & dependencies
.git
node_modules/
__pycache__/

# Log files and environment
*.log
.env

# Operating system & IDE files
.DS_Store
.vscode/

# Docker files themselves
Dockerfile
.dockerignore
docker-compose.yml

Docker Networking Management

Docker Networking allows containers to communicate with each other and connect to external networks. By default, containers are isolated and can only communicate if they're on the same network.

Types of Networks in Docker

1. Bridge (Default): Docker's default virtual network for communication between containers in the same network.

bash

# Create bridge network
docker network create --driver bridge <network_name>

# Run container and connect directly to network
docker run -d --name <container1> --network <network_name> <image1>
docker run -d --name <container2> --network <network_name> <image2>

# Create bridge network
docker network create --driver bridge <network_name>

# Run container and connect directly to network
docker run -d --name <container1> --network <network_name> <image1>
docker run -d --name <container2> --network <network_name> <image2>

2. Host: Container shares network directly with host (Linux only).

bash

# Create host network (Linux)
docker run --rm --network host <image_name>

# Create host network (Linux)
docker run --rm --network host <image_name>

3. None: Container will have no network access at all.

bash

# Create none network
docker run --rm --network none <image_name>

# Create none network
docker run --rm --network none <image_name>

Basic Docker Networking Commands

bash

# View network list
docker network ls

# Create network
docker network create <network_name>

# Delete network
docker network rm <network_name>

# View network list
docker network ls

# Create network
docker network create <network_name>

# Delete network
docker network rm <network_name>

Container Management in Network

bash

# Connect container when created
docker container create --name <container_name> \
  --network <network_name> \
  <image_name>:<tag>

# Connect existing container
docker network connect <network_name> <container_name>

# Disconnect container from network
docker network disconnect <network_name> <container_name>

# Connect container when created
docker container create --name <container_name> \
  --network <network_name> \
  <image_name>:<tag>

# Connect existing container
docker network connect <network_name> <container_name>

# Disconnect container from network
docker network disconnect <network_name> <container_name>

Inter-Container Communication (containers in the same network can communicate using container names)

bash

# Container A can access Container B with:
http://container-b:port

# Container A can access Container B with:
http://container-b:port

Docker Volume and Persistent Storage Management

Data inside containers is temporary. If a container is deleted, the data is also lost. To store data permanently, use:

Bind Mount

Bind mount is a method for sharing files or folders from the host system into a container. Data is managed directly by the host file system, with file or folder locations specified explicitly. This method is useful when you want to access or update files from outside the container.

Common Bind Mount Commands:

bash

# Using bind mount in container
docker run --rm \
  --mount type=bind,source=<host_path>,destination=<container_path> \
  <image_name>

# Using bind mount in container
docker run --rm \
  --mount type=bind,source=<host_path>,destination=<container_path> \
  <image_name>

Docker Volume (Recommended)

Docker volume is a storage area managed directlyby Docker, which is safer, portable, and doesn't depend on host file structure. Volumes provide consistency across environments, support easy backup and restore processes, and can be managed through Docker CLI commands.

Common Docker Volume Commands:

bash

# Create volume
docker volume create volume_name

# Use volume in container
docker run --rm \
  --mount type=volume,source=<host_path>,destination=<container_path> \
  <image_name>

# View volume list
docker volume ls

# Delete volume
docker volume rm <volume_name>

# Create volume
docker volume create volume_name

# Use volume in container
docker run --rm \
  --mount type=volume,source=<host_path>,destination=<container_path> \
  <image_name>

# View volume list
docker volume ls

# Delete volume
docker volume rm <volume_name>

Volume Backup & Restore

Volume backup and restore is done by creating temporary containers that mount the target volume and local folder as backup or restore location. The purpose of backup is to store copies of volume data for future use, while the purpose of restore is to return data to a volume from previously created backup copies.

Volume Backup & Restore Commands:

bash

# Backup volume
docker container run --rm --name <backup_container_name> \
  --mount type=bind,source=<host_backup_path>,destination=/backup \
  --mount type=volume,source=<volume_name>,destination=/data \
  <image_name> tar cvf /backup/<backup_file_name>.tar.gz /data

# Restore volume
docker container run --rm --name <restore_container_name> \
  --mount type=bind,source=<host_backup_path>,destination=/backup \
  --mount type=volume,source=<restore_volume_name>,destination=/data \
  <image_name> tar xvf /backup/<backup_file_name>.tar.gz -C /data --strip-components 1

# Backup volume
docker container run --rm --name <backup_container_name> \
  --mount type=bind,source=<host_backup_path>,destination=/backup \
  --mount type=volume,source=<volume_name>,destination=/data \
  <image_name> tar cvf /backup/<backup_file_name>.tar.gz /data

# Restore volume
docker container run --rm --name <restore_container_name> \
  --mount type=bind,source=<host_backup_path>,destination=/backup \
  --mount type=volume,source=<restore_volume_name>,destination=/data \
  <image_name> tar xvf /backup/<backup_file_name>.tar.gz -C /data --strip-components 1

Docker Compose Management

Docker Compose is a tool for defining and running multi-container Docker applications using a docker-compose.yml configuration file. Very useful for managing interdependent services, such as web applications and databases.

docker-compose.yml Template

yaml

# Compose version
version: '3.8'

# Application services
services:
  # Web app
  web:
    build: .
    ports:
      - '8000:8000'
    depends_on:
      - database
    restart: always

  # Database
  database:
    image: postgres:13
    environment:
      POSTGRES_PASSWORD: password
    volumes:
      - db_data:/var/lib/postgresql/data
    restart: always

# Volume for data
volumes:
  db_data:

# Compose version
version: '3.8'

# Application services
services:
  # Web app
  web:
    build: .
    ports:
      - '8000:8000'
    depends_on:
      - database
    restart: always

  # Database
  database:
    image: postgres:13
    environment:
      POSTGRES_PASSWORD: password
    volumes:
      - db_data:/var/lib/postgresql/data
    restart: always

# Volume for data
volumes:
  db_data:

Common Docker Compose Commands

bash

# Run all services (background)
docker compose up -d

# Stop and remove all containers
docker compose down

# View container status
docker compose ps

# Rebuild image before running
docker compose up --build

# Run all services (background)
docker compose up -d

# Stop and remove all containers
docker compose down

# View container status
docker compose ps

# Rebuild image before running
docker compose up --build

4. Hands-On Practices with Docker

Here's a complete and sequential tutorial for learning Docker from basics to deploying to Docker Hub with GitLab CI/CD integration. We'll create a simple web application using Python Flask.

Prerequisites

Docker installed on your system
Docker Hub account
GitLab account
Git installed

Step 1: Creating Basic Dockerfile and Image

In this first step, we'll learn basic Docker concepts by creating a simple Flask application and packaging it into a Docker container. This is the foundation for understanding how Docker works in packaging and running applications.

1. Create project directory

bash

mkdir docker-tutorial
cd docker-tutorial

mkdir docker-tutorial
cd docker-tutorial

2. Create `app.py` file (simple Flask application)

python

from flask import Flask, render_template
app = Flask(__name__)

@app.route('/')
def home():
    return render_template('index.html')

if __name__ == '__main__':
    app.run(host='0.0.0.0', port=5000)

from flask import Flask, render_template
app = Flask(__name__)

@app.route('/')
def home():
    return render_template('index.html')

if __name__ == '__main__':
    app.run(host='0.0.0.0', port=5000)

3. Create `requirements.txt` file

plaintext

flask==2.3.3

flask==2.3.3

4. Create `Dockerfile`

plaintext

# Use official Python image as base image
FROM python:3.12

# Set working directory in container
WORKDIR /app

# Copy requirements file first to utilize layer caching
COPY requirements.txt .

# Install dependencies
RUN pip install --no-cache-dir -r requirements.txt

# Copy entire application code
COPY . .

# Expose port used by Flask
EXPOSE 5000

# Command to run the application
CMD ["python", "app.py"]

# Use official Python image as base image
FROM python:3.12

# Set working directory in container
WORKDIR /app

# Copy requirements file first to utilize layer caching
COPY requirements.txt .

# Install dependencies
RUN pip install --no-cache-dir -r requirements.txt

# Copy entire application code
COPY . .

# Expose port used by Flask
EXPOSE 5000

# Command to run the application
CMD ["python", "app.py"]

5. Create `templates/` folder and `templates/index.html` file

html

<!DOCTYPE html>
<html lang="en">
  <head>
    <meta charset="UTF-8" />
    <title>Hello Docker</title>
    <style>
      body {
        font-family: 'Segoe UI', Tahoma, Geneva, Verdana, sans-serif;
        background: linear-gradient(to right, #00b4db, #0083b0);
        color: #fff;
        text-align: center;
        padding-top: 100px;
        margin: 0;
      }

      h1 {
        font-size: 48px;
        margin-bottom: 20px;
      }

      p {
        font-size: 20px;
        opacity: 0.9;
      }

      .card {
        background: rgba(255, 255, 255, 0.1);
        border-radius: 15px;
        padding: 30px;
        max-width: 500px;
        margin: auto;
        box-shadow: 0 10px 25px rgba(0, 0, 0, 0.2);
      }
    </style>
  </head>
  <body>
    <div class="card">
      <h1>Hello World! 🚀</h1>
      <p>Getting Started with Your App using Docker!</p>
    </div>
  </body>
</html>

<!DOCTYPE html>
<html lang="en">
  <head>
    <meta charset="UTF-8" />
    <title>Hello Docker</title>
    <style>
      body {
        font-family: 'Segoe UI', Tahoma, Geneva, Verdana, sans-serif;
        background: linear-gradient(to right, #00b4db, #0083b0);
        color: #fff;
        text-align: center;
        padding-top: 100px;
        margin: 0;
      }

      h1 {
        font-size: 48px;
        margin-bottom: 20px;
      }

      p {
        font-size: 20px;
        opacity: 0.9;
      }

      .card {
        background: rgba(255, 255, 255, 0.1);
        border-radius: 15px;
        padding: 30px;
        max-width: 500px;
        margin: auto;
        box-shadow: 0 10px 25px rgba(0, 0, 0, 0.2);
      }
    </style>
  </head>
  <body>
    <div class="card">
      <h1>Hello World! 🚀</h1>
      <p>Getting Started with Your App using Docker!</p>
    </div>
  </body>
</html>

6. Build Docker image

bash

docker build -t my-flask-app .

docker build -t my-flask-app .

7. Run container

bash

docker run -d -p 5000:5000 --name flask-container my-flask-app

docker run -d -p 5000:5000 --name flask-container my-flask-app

8. Open browser and access `http://localhost:5000/` to view the application.

9. Stop and remove container

bash

docker stop flask-container
docker rm flask-container

docker stop flask-container
docker rm flask-container

Step 2: Using Docker Volume

Docker Volume is a feature that allows us to store data persistently outside containers. In this step, we'll try creating a simple volume and using it when running containers.

1. Create Docker volume

bash

docker volume create flask-data

docker volume create flask-data

2. Run container with volume to store data

bash

docker run -d -p 5000:5000 --name flask-container -v flask-data:/app/data my-flask-app

docker run -d -p 5000:5000 --name flask-container -v flask-data:/app/data my-flask-app

3. Verify volume

bash

docker volume inspect flask-data

docker volume inspect flask-data

4. Log if successful

json

[
  {
    "CreatedAt": "2025-07-27T12:57:02+07:00",
    "Driver": "local",
    "Labels": null,
    "Mountpoint": "/var/lib/docker/volumes/flask-data/_data",
    "Name": "flask-data",
    "Options": null,
    "Scope": "local"
  }
]

[
  {
    "CreatedAt": "2025-07-27T12:57:02+07:00",
    "Driver": "local",
    "Labels": null,
    "Mountpoint": "/var/lib/docker/volumes/flask-data/_data",
    "Name": "flask-data",
    "Options": null,
    "Scope": "local"
  }
]

5. Stop and remove container

bash

docker stop flask-container
docker rm flask-container

docker stop flask-container
docker rm flask-container

Step 3: Using Docker Network

Docker Network allows containers to communicate with each other safely and in isolation. In this step, we'll try creating a simple custom network and running containers within it.

1. Create Docker network

bash

docker network create flask-network

docker network create flask-network

2. Run container with the created network

bash

docker run -d -p 5000:5000 --name flask-container --network flask-network my-flask-app

docker run -d -p 5000:5000 --name flask-container --network flask-network my-flask-app

3. Verify network

bash

docker network inspect flask-network

docker network inspect flask-network

4. Log if successful

json

[
  {
    "Name": "flask-network",
    "Id": "ce89c2ab75c528d162f651a135beabd4dbd43c8a7d9344ac8d702ba55d4873fb",
    "Created": "2025-07-27T12:57:56.113078894+07:00",
    "Scope": "local",
    "Driver": "bridge",
    "EnableIPv4": true,
    "EnableIPv6": false,
    "IPAM": {
      "Driver": "default",
      "Options": {},
      "Config": [
        {
          "Subnet": "172.18.0.0/16",
          "Gateway": "172.18.0.1"
        }
      ]
    },
    "Internal": false,
    "Attachable": false,
    "Ingress": false,
    "ConfigFrom": {
      "Network": ""
    },
    "ConfigOnly": false,
    "Containers": {
      "9d1028daf54597527bc6b72a17129d0bfd03173566e398b87dad3abb69a01250": {
        "Name": "flask-container",
        "EndpointID": "6dfca38bba5f7e359da06c6f8190a209fec96d5e6fd5c3750a0125dc72c3eaef",
        "MacAddress": "be:2d:bf:9a:74:0e",
        "IPv4Address": "172.18.0.2/16",
        "IPv6Address": ""
      }
    },
    "Options": {},
    "Labels": {}
  }
]

[
  {
    "Name": "flask-network",
    "Id": "ce89c2ab75c528d162f651a135beabd4dbd43c8a7d9344ac8d702ba55d4873fb",
    "Created": "2025-07-27T12:57:56.113078894+07:00",
    "Scope": "local",
    "Driver": "bridge",
    "EnableIPv4": true,
    "EnableIPv6": false,
    "IPAM": {
      "Driver": "default",
      "Options": {},
      "Config": [
        {
          "Subnet": "172.18.0.0/16",
          "Gateway": "172.18.0.1"
        }
      ]
    },
    "Internal": false,
    "Attachable": false,
    "Ingress": false,
    "ConfigFrom": {
      "Network": ""
    },
    "ConfigOnly": false,
    "Containers": {
      "9d1028daf54597527bc6b72a17129d0bfd03173566e398b87dad3abb69a01250": {
        "Name": "flask-container",
        "EndpointID": "6dfca38bba5f7e359da06c6f8190a209fec96d5e6fd5c3750a0125dc72c3eaef",
        "MacAddress": "be:2d:bf:9a:74:0e",
        "IPv4Address": "172.18.0.2/16",
        "IPv6Address": ""
      }
    },
    "Options": {},
    "Labels": {}
  }
]

5. Stop and remove container

bash

docker stop flask-container
docker rm flask-container

docker stop flask-container
docker rm flask-container

Step 4: Using Docker Compose

After successfully running applications using manual commands (build image, run container, connect volume and network), it's time to simplify everything using Docker Compose.

Docker Compose allows us to define entire application configuration (services, volumes, networks) in one YAML file. This greatly helps in team collaboration and deployment automation.

1. Create `docker-compose.yml` file

yaml

version: '3.8' # (optional) No longer applies in Compose V2, can be removed

services:
  web:
    build: .
    ports:
      - '5000:5000'
    volumes:
      - flask-data:/app/data # Volume name
    networks:
      - flask-net # Network name

volumes:
  flask-data: # Volume definition

networks:
  flask-net: # Network definition
    driver: bridge # Using bridge driver

version: '3.8' # (optional) No longer applies in Compose V2, can be removed

services:
  web:
    build: .
    ports:
      - '5000:5000'
    volumes:
      - flask-data:/app/data # Volume name
    networks:
      - flask-net # Network name

volumes:
  flask-data: # Volume definition

networks:
  flask-net: # Network definition
    driver: bridge # Using bridge driver

2. Run application with Docker Compose

bash

docker-compose up -d

docker-compose up -d

3. To stop

bash

docker-compose down

docker-compose down

Step 5: Publish Image to Docker Hub

Docker Hub is a public registry for storing and sharing Docker images. In this step, we'll publish the image we created to Docker Hub so it can be accessed and used by others from anywhere. This is very useful for application distribution and team collaboration.

1. Login to Docker Hub from terminal

bash

docker login

docker login

2. Tag image with `username/repository:tag` format

bash

docker tag my-flask-app <username>/my-flask-app:latest

docker tag my-flask-app <username>/my-flask-app:latest

3. Push image to Docker Hub

bash

docker push <username>/my-flask-app:latest

docker push <username>/my-flask-app:latest

4. Verify the image in Docker Hub

Open https://hub.docker.com/repositories/ and ensure the image is successfully published and appears in the account's repository list.

Step 6: Test Pull Image from Docker Hub and Run on Server (Optional)

In this step, we'll test the process of pulling images from Docker Hub and running them in different environments (can be on server or local). This demonstrates one of Docker's advantages: portability - the same image can run anywhere consistently.

⚠️ Note: This step is not mandatory to run on a server, it can also be done locally. But make sure there are no containers or images with the same name.

If they already exist and are still active:

bash

docker stop flask-app       # Stop container
docker rm flask-app         # Remove container
docker rmi <username>/my-flask-app:latest  # (optional) Remove old image

docker stop flask-app       # Stop container
docker rm flask-app         # Remove container
docker rmi <username>/my-flask-app:latest  # (optional) Remove old image

1. (If on server) Login to server

bash

ssh <user>@<server_ip>

ssh <user>@<server_ip>

2. Pull image from Docker Hub

bash

docker pull <username>/my-flask-app:latest

docker pull <username>/my-flask-app:latest

Replace username with your Docker Hub account name that was pushed earlier.

3. Run container from that image

bash

docker run -d --name <container_name> -p 5000:5000 <username>/my-flask-app:latest

docker run -d --name <container_name> -p 5000:5000 <username>/my-flask-app:latest

The -d option runs in background, -p to map host:container port.

4. Access application in browser

Open http://localhost:5000 (local) or http://<server-ip>:5000 (server).

Here's the result of the application successfully running through the server.

Step 7: Automate Build & Push with GitLab

After successfully building images locally, uploading them to Docker Hub, and pulling images on the server, the next step is to automate the build and push image process using GitLab CI/CD. With GitLab pipeline, this process will run automatically every time you push to the repository.

GitLab CI allows us to run Docker-based CI/CD processes through the .gitlab-ci.yml file. For the Continuous Delivery stage, simply do docker pull on the server and restart the container so changes can be applied.

1. Create `.gitlab-ci.yml` file in project root

This file will instruct GitLab CI/CD to build and push Docker images.

yaml

# Use Docker image & enable Docker-in-Docker
image: docker:latest
services:
  - docker:dind

# Variables for Docker configuration
variables:
  DOCKER_DRIVER: overlay2
  IMAGE_NAME: $CI_REGISTRY_USER/my-flask-app

before_script:
  # Login to GitLab Container Registry
  - echo "$CI_REGISTRY_PASSWORD" | docker login -u "$CI_REGISTRY_USER"
    --password-stdin

build:
  stage: build
  script:
    # Build & push Docker image
    # Use tag latest_v2 because index.html will be updated (previously latest)
    - docker build -t $IMAGE_NAME:latest_v2 .
    - docker push $IMAGE_NAME:latest_v2

# Use Docker image & enable Docker-in-Docker
image: docker:latest
services:
  - docker:dind

# Variables for Docker configuration
variables:
  DOCKER_DRIVER: overlay2
  IMAGE_NAME: $CI_REGISTRY_USER/my-flask-app

before_script:
  # Login to GitLab Container Registry
  - echo "$CI_REGISTRY_PASSWORD" | docker login -u "$CI_REGISTRY_USER"
    --password-stdin

build:
  stage: build
  script:
    # Build & push Docker image
    # Use tag latest_v2 because index.html will be updated (previously latest)
    - docker build -t $IMAGE_NAME:latest_v2 .
    - docker push $IMAGE_NAME:latest_v2

2. Create a new GitLab project

Select the New Project → Create blank project menu.

After the project is created, initialize Git in local folder and connect to GitLab.

bash

git init
git remote add origin https://gitlab.com/username/your-repo.git

git init
git remote add origin https://gitlab.com/username/your-repo.git

3. Set environment variables in GitLab

Go to your GitLab project → Settings → CI/CD → click Expand on Variables section
Add two variables:
- CI_REGISTRY_USER → fill with Docker Hub username
- CI_REGISTRY_PASSWORD → fill with Docker Hub password/token
For each variable, set options as follows:
- Mask variable (check if you want the value not to appear in logs)
- Protect variable (leave unchecked if you want it to be usable on all branches)

4. Change `index.html` content to see changes when pulling image

Edit index.html file (or other HTML files) so the changes are visible when pulled from server.

html

<!DOCTYPE html>
<html lang="en">
  <head>
    <meta charset="UTF-8" />
    <title>Hello Docker</title>
    <style>
      body {
        font-family: 'Segoe UI', Tahoma, Geneva, Verdana, sans-serif;
        background: linear-gradient(to right, #00b4db, #0083b0);
        color: #fff;
        text-align: center;
        padding: 50px 20px;
        margin: 0;
      }

      h1 {
        font-size: 48px;
        margin-bottom: 20px;
      }

      p {
        font-size: 20px;
        opacity: 0.9;
        margin-bottom: 30px;
      }

      .card {
        background: rgba(255, 255, 255, 0.1);
        border-radius: 15px;
        padding: 30px;
        max-width: 500px;
        margin: 20px auto;
        box-shadow: 0 10px 25px rgba(0, 0, 0, 0.2);
        transition: transform 0.3s ease;
      }

      .card:hover {
        transform: translateY(-5px);
      }

      .card-container {
        display: flex;
        flex-wrap: wrap;
        justify-content: center;
        gap: 20px;
        max-width: 1100px;
        margin: 0 auto;
      }

      .card h2 {
        margin-top: 0;
        color: #fff;
      }

      .card p {
        margin-bottom: 0;
      }
    </style>
  </head>
  <body>
    <div class="card-container">
      <div class="card">
        <h1>Hello World! 🚀</h1>
        <p>Getting Started with Your App using Docker!</p>
      </div>

      <div class="card">
        <h2>Docker Features</h2>
        <p>✔ Containerization made easy</p>
        <p>✔ Lightweight and portable</p>
        <p>✔ CI/CD integration ready</p>
      </div>

      <div class="card">
        <h2>Next Steps</h2>
        <p>➡ Build your Docker image</p>
        <p>➡ Push to container registry</p>
        <p>➡ Deploy anywhere!</p>
      </div>
    </div>
  </body>
</html>

<!DOCTYPE html>
<html lang="en">
  <head>
    <meta charset="UTF-8" />
    <title>Hello Docker</title>
    <style>
      body {
        font-family: 'Segoe UI', Tahoma, Geneva, Verdana, sans-serif;
        background: linear-gradient(to right, #00b4db, #0083b0);
        color: #fff;
        text-align: center;
        padding: 50px 20px;
        margin: 0;
      }

      h1 {
        font-size: 48px;
        margin-bottom: 20px;
      }

      p {
        font-size: 20px;
        opacity: 0.9;
        margin-bottom: 30px;
      }

      .card {
        background: rgba(255, 255, 255, 0.1);
        border-radius: 15px;
        padding: 30px;
        max-width: 500px;
        margin: 20px auto;
        box-shadow: 0 10px 25px rgba(0, 0, 0, 0.2);
        transition: transform 0.3s ease;
      }

      .card:hover {
        transform: translateY(-5px);
      }

      .card-container {
        display: flex;
        flex-wrap: wrap;
        justify-content: center;
        gap: 20px;
        max-width: 1100px;
        margin: 0 auto;
      }

      .card h2 {
        margin-top: 0;
        color: #fff;
      }

      .card p {
        margin-bottom: 0;
      }
    </style>
  </head>
  <body>
    <div class="card-container">
      <div class="card">
        <h1>Hello World! 🚀</h1>
        <p>Getting Started with Your App using Docker!</p>
      </div>

      <div class="card">
        <h2>Docker Features</h2>
        <p>✔ Containerization made easy</p>
        <p>✔ Lightweight and portable</p>
        <p>✔ CI/CD integration ready</p>
      </div>

      <div class="card">
        <h2>Next Steps</h2>
        <p>➡ Build your Docker image</p>
        <p>➡ Push to container registry</p>
        <p>➡ Deploy anywhere!</p>
      </div>
    </div>
  </body>
</html>

5. Push Code and Run Pipeline

bash

git add .
git commit -m "Initial commit with Docker setup"
git push -u origin main

git add .
git commit -m "Initial commit with Docker setup"
git push -u origin main

6. Verify Pipeline

Open CI/CD → Pipelines menu in GitLab
Click the latest pipeline that appears, then open the job named build
In the log (terminal output), make sure the following processes appear without errors:
- docker login → successfully logged into Docker Hub
- docker build → image successfully built
- docker push → image successfully sent to Docker Hub
Finally, open your Docker Hub account and check if the image has appeared or been successfully updated

Step 8: Deploy Latest Changes with docker pull

After the GitLab pipeline successfully builds and pushes the new image, simply do docker pull and restart the container to apply updates.

The steps are similar to Step 6, just replace with the latest tag:

bash

# (Optional) Stop and remove old container
docker stop flask-app
docker rm flask-app

# Pull latest image version
docker pull <username>/my-flask-app:latest_v2

# Restart container
docker run -d --name flask-app -p 5000:5000 <username>/my-flask-app:latest_v2

# (Optional) Stop and remove old container
docker stop flask-app
docker rm flask-app

# Pull latest image version
docker pull <username>/my-flask-app:latest_v2

# Restart container
docker run -d --name flask-app -p 5000:5000 <username>/my-flask-app:latest_v2

The application will now display the latest version according to the last index.html update in GitLab.

Final Project Structure

plaintext

docker-tutorial/
├── app.py
├── Dockerfile
├── docker-compose.yml
├── .gitlab-ci.yml
├── requirements.txt
└── templates/
    └── index.html

docker-tutorial/
├── app.py
├── Dockerfile
├── docker-compose.yml
├── .gitlab-ci.yml
├── requirements.txt
└── templates/
    └── index.html

Responses (0)

1. Introduction to Containerization and Docker

What is Containerization?

What is Docker?

2. Understanding Docker Architecture

Docker Engine

Docker Image

Docker Container

Docker Registry

Docker Networking

Docker Volume

Docker Compose

3. Getting Started with Docker

Docker Installation

Managing Docker Images and Docker Containers

Dockerfile and Building Images

Build Optimization with .dockerignore

Docker Networking Management

Docker Volume and Persistent Storage Management

Bind Mount

Docker Volume (Recommended)

Volume Backup & Restore

Docker Compose Management

4. Hands-On Practices with Docker

Prerequisites

Step 1: Creating Basic Dockerfile and Image

1. Create project directory

2. Create app.py file (simple Flask application)

3. Create requirements.txt file

4. Create Dockerfile

5. Create templates/ folder and templates/index.html file

6. Build Docker image

7. Run container

8. Open browser and access http://localhost:5000/ to view the application.

9. Stop and remove container

Step 2: Using Docker Volume

1. Create Docker volume

2. Run container with volume to store data

3. Verify volume

4. Log if successful

5. Stop and remove container

Step 3: Using Docker Network

1. Create Docker network

2. Run container with the created network

3. Verify network

4. Log if successful

5. Stop and remove container

Step 4: Using Docker Compose

1. Create docker-compose.yml file

2. Run application with Docker Compose

3. To stop

Step 5: Publish Image to Docker Hub

1. Login to Docker Hub from terminal

2. Tag image with username/repository:tag format

3. Push image to Docker Hub

4. Verify the image in Docker Hub

Step 6: Test Pull Image from Docker Hub and Run on Server (Optional)

1. (If on server) Login to server

2. Pull image from Docker Hub

3. Run container from that image

4. Access application in browser

Step 7: Automate Build & Push with GitLab

1. Create .gitlab-ci.yml file in project root

2. Create a new GitLab project

3. Set environment variables in GitLab

4. Change index.html content to see changes when pulling image

5. Push Code and Run Pipeline

6. Verify Pipeline

Step 8: Deploy Latest Changes with docker pull

Final Project Structure

References

Build Optimization with `.dockerignore`

2. Create `app.py` file (simple Flask application)

3. Create `requirements.txt` file

4. Create `Dockerfile`

5. Create `templates/` folder and `templates/index.html` file

8. Open browser and access `http://localhost:5000/` to view the application.

1. Create `docker-compose.yml` file

2. Tag image with `username/repository:tag` format

1. Create `.gitlab-ci.yml` file in project root

4. Change `index.html` content to see changes when pulling image
